PC Board Reverse Engineering

PC Board Reverse Engineering is a complex process during which the time and energy is consuming very fast. In order to prevent any mistakes occurs during this process we need to inspect items general drawing:

1. If the pc board circuit drawing has been analyzed or not; has it been separated into basic unit for smooth circuit?

2. if the circuit allow to use short or isolated critical lead?

3. those areas which need to be shielded have been shielded effectively?

4. if the basic network grid of pc board has been fully applied or not?

5. if the pc board dimension is optimum, otherwise, we can change it on the PCB Reverse engineering process?

6. if all the tracks width and space are all chosen?

7. if the PAD dimension and hole dimension have been chosen optimized?

8. if the film image and sketch is properly?

9. if the minimum cross line has been applied on pc board reverse engineering and if all of them need to go through the components or accessory?

10. all the marking on the pc board can be seen or not? Are their dimension and part number is correct?

11. if the opening on the large area of copper has been fully reverse engineering on the pc board to prevent the bubble on the solder resist?

12. is there any place for tooling holes?
