Automatically Printed Wiring Board Reverse Engineering

Automatically Printed Wiring Board Reverse Engineering can only be applied after the critical signal tracks are all fixed, for these tracks reverse engineering, some electrical parameters must be taken into consideration, such as decrease the inductor allocation area. After understanding what kind of electrical parameter it will input and the effect the quality of automatic reverse engineering can be guarantee to success

General rules must be applied for critical PCB board signal track reverse engineering, through the installation of restriction terms and prohibit the Reverse Engineering area can limit the layer count for signal Reverse Engineering as well as the through hole quantity. Tools can Reverse Engineering automatically according to the engineer expectation. Once the restriction rules and created rules being fixed, the result can be closed to the expectation.

The number of PCB board will be determined by the complexity level of circuit and the general rules of it. Nowadays, the automatic tools is powerful and can also finish all the jobs. However, if any one of signal haven’t been finished by automatic PCB Reverse Engineering, engineer need to do it manually.
